The BOLT 8' – 6 Lamp LED Shop Light – 18,600 Lumens CLEAR

The New 8 Foot Version Of The 3 Lamp Bolt Uses 4 Foot Lamps!
Fixture Made in the USA

120 WATT 8 FOOT LED STRIP FIXTURE

COMMERCIAL SPECIFICATION GRADE

Shipping: FREE, In Stock

Certifications: UL Listed, NSF Certified, Damp Rated

Warranty: 5 years on complete fixture including LED lamps

Specifications:

The 8 foot Bolt LED shop light combines 6 clear finish lamps to bring energy-efficient and bright lighting into garages, warehouses, or anywhere else where professional-grade lighting is needed. Our Bolt LED shop light uses a simple extension plate for quick assembly and can be installed with a single point of wiring. Double rows of 4 foot lamps eliminate much of the cost, fragility, and hassle that can come with traditional 8 feet shop lights. Most standard 8ft lamps are unable to match the efficiency, brightness, and durability of the combined PrimeLights 4 foot lamps.

We manufacture our commercial-grade 8 foot LED shop light fixtures using heavy-duty 24 gauge steel, finished with a white post painted baked-on enamel. Performing regular maintenance is not required, and many LED bulbs have a life expectancy of 40+ years when running 4 hours per day. Our Bolt 8 foot LED shop light is rated and certified for use in damp locations, so they can be used in garages, warehouses, farms, and other areas that require durable and long-lasting lighting solutions. Containing no glass or mercury, LED bulbs are environmentally friendly and virtually indestructible. When purchasing a Bolt LED shop light fixture from PrimeLights, you can trust that you’re securing one of the best lighting solutions on the market.

Input Wattage: 120W

Voltage: 110-277V

LED Lumens: 18,600

Lumens per watt: 155+

Equivalent Lumens: 35,340

Life: 50,000 Hours +

Color Temperature: 5000K daylight white (call for others)

CRI: 85+

Beam Angle: 120°

Amperage @ 120V: 1A

Amperage @ 277V: 0.43A

Included Lamps: (6) 4' flicker-free, shatterproof polycarbonate (imported)

Base Type: G13 Medium B-Pin

Lamp Lens: Clear

Minimum Start Temp: -30° C

Maximum Start Temp: 50° C

Length: 96"  Width: 4.5"  Depth: 3.5"

Mounting Options:

-Surface mountable

-Chain hang (cable hangers sold in accessories)

-This fixture is ready for hard wire install - please see accessories for items such as plug and cord and occupancy sensors.

*Energy Usage: Approx. 40% Less than T8 Fluorescent

 Applications: 8ft Fluorescent Replacement, Warehouse, machine shops, pole barns, farms, ranches, auto shops, work shops, welding shops, airplane hangar, etc.

 Lighting Layouts: As a rough estimate, change these out 1 for 1 with any 8' technology to really brighten things us.  For new applications, recommended mounting heights are 8' - 20'  and approx 1 fixture per 450 sf as a rough guide.  There are many other factors in deciding the proper light level (mounting height, application / preferred light levels, building reflectivity, etc).  For a professional lighting layout, please call customer service.  These are no charge and only take a few minutes over the phone.  Please be prepared to tell us the following: length, width, height and application of the building.  Call 512-746-7428.  Our layouts our guaranteed to satisfy!
